Diode Laser HS-818
Short Description:
The high density diode laser using exclusive ultra short pulse technology, it enables the delivery of ultra short pulses (1ms) at 1600W high peak power with high fluence in large spot, which guarantee effectiveness, shorten treatment session and residual hair.
The high density diode laser using exclusive ultra short pulse technology, it enables the delivery of ultra short pulses (1ms) at 1600W high peak power with high fluence in large spot, which guarantee effective, shorten treatment session and residual hair.
ULTRA SHORT PULSE WIDTH
Based on solid-state laser, the technology enables treatment to be done at 1600W high peak power deliverying the energy in ultra short pulse (1ms), which makes more fast & effective in treatment, especially for white skin/fine hair and blond hair.
CONTACT COOLING SAPPHIRE TIP
Dualwave 810nm
The laser handpiece head is fitted with sapphire tip that increase safety of the patients and minimises pain during treatment. Ensuring a constant temperature of -4℃ to 4℃ at the tip of handpiece, allowing it to work with high power and big spot size guaranteeing the safety of treatment.
1600W 12x14mm
SMART PRE-SET TREATMENT PROTOCOLS
You can adjust the settings precisely in PROFESSIONAL MODE for the skin, colour and hair type and the hair thickness, thereby offering clients maximum safety and effectiveness in their personalised treatment.
Using the intuitive touch screen, you can select the required 3 modes and programmes. The device recognises different handpiece types used and automatically adapts the configuration circle to it, giving pre-set recommended treatment protocols.
| Laser output | 1600W |
| Spot size | 12x14mm |
|
Wavelength |
810nm or Dualwave |
|
Energy density |
72J/cm2 |
|
Repetition rate |
1-15Hz |
|
Pulse width |
1-200ms |
|
Operate interface |
9.7’’ true color touch screen |
|
Dimension |
61*44*111cm (L*W*H) |
|
Weight |
55Kgs |
* OEM/ODM project supported.
TREATMENT APPLICATION
Permanent hair removal and skin rejuvenation.
755nm: Recommended for white skin (phototypes I-III) with fine/blond hair
810nm: Golden standard for depilation, recommended for all skin phototypes, particularly patients with a great density of hair.
Dualwave: Combine 755nm and 810nm in one single laser handle.
Triplewave: Combine 755nm, 810nm and 1064nm in one single laser handle, suitable for all skin types.
