EO Q-Switch ND YAG Laser HS-290
Short Description:
The 4 wavelengths(1064/532/585/650nm) EO Q-switched Nd: YAG laser has been engineered to meet the growing demands of busy clinics, and includes a variety of efficacious treatment options, smart pre-set treatment protocols, built-in safety, minimized downtime, all at an affordable price.
Specification Of HS-290
|
Laser Type |
EO Q-switch Nd:YAG laser |
||
|
Wavelength |
1064/532/585/650nm |
||
|
Operate mode |
Q-switched mode & SPT mode |
||
|
Beam profile |
Flat-top mode |
||
|
Pulse width |
≤6ns (Q-switched mode) |
||
|
300us (SPT mode) |
|||
|
Pulse Energy HS-290HS-290E |
Q-switch 1064nm |
Q-switched 532nm |
SPT mode (1064nm long pulse) |
|
Max. 2000mJ |
Max. 1000mJ |
Max. 2800mJ |
|
|
Max. 800mJ |
Max. 400mJ |
Max. 1200mJ |
|
|
Energy calibration |
External & self-restoration |
||
|
Spot size |
2-10mm |
||
|
Repetition rate |
Max. 10Hz (1064nm, 532nm, SPT mode) |
||
|
Optical delivery |
Articulated arm |
||
|
Operate Interface |
9.7″ True color touch screen |
||
|
Aiming beam |
Diode laser 655nm (Red) |
||
|
Cooling system |
Advanced air & water cooling system |
||
|
Power supply |
AC110V or 230V, 50/60HZ |
||
|
Dimension |
HS-290: 82*30*88cm (L*W*H) HS-290E: 75*30*88cm (L*W*H) |
||
|
Weight |
HS-290: 80Kgs HS-290E: 70Kgs |
||
Application Of HS-290
● Tattoo
● Vascular Rejuvenation
● Skin Rejuvenation
● Epidermal and dermal pigmented lesions: Nevus of Ota, Sun damage, Melasma
● Skin resurfacing: wrinkle reduction, Acne scar reduction, Skin toning
Advantage Of HS-290
The 4 wavelengths(1064/532/585/650nm) EO Q-switched Nd: YAG laser has been engineered to meet the growing demands of busy clinics, and includes a variety of efficacious treatment options, smart pre-set treatment protocols, built-in safety, minimized downtime, all at an affordable price.
Wavelengths
Uniform flat-top beam profile
High peak power
Aiming beam
Pre-set treatment protocols
Auto-calibration and self-restoration
SPT mode
Ergonomic
1064/532nm
585nm dye laser tip (optional)
650nm dye laser tip (optional)
UNIFORM TOP HAT BEAM PROFILE
The articulated arm assure a flat top beam profile due to its advanced optical technology, able to distribute the laser power homogeneously all over the spot size. It has squared, rounded and fractionated beam profiles, which ensure maximizing the delivery of energy in deep skin while minimizing damage to surrounding tissue.
SMART PRE-SET TREATMENT PROTOCOLS
Using the intuitive touch screen, you can select the required mode and programmes. The device recognizes and automatically adapts the configuration, giving pre-set recommended treatment protocols.
Before & After
